Products/IP cameras/IPVD-SB5IRZ
IPVD-SB5IRZ 5MP Motorized Lens IP Vandal Dome
Open full-resolution image

IPVD-SB5IRZ

5MP Motorized Lens IP Vandal Dome

A 5MP IP vandal dome with a motorized lens for adjusting the scene during commissioning. Compare it with a fixed-lens model when the final framing is uncertain. Check mounting clearances and the environmental specifications for the intended camera position.

Product datasheet View at Security Camera King

Pricing and availability are provided by our authorized reseller.

Technical specifications

FeaturesH.265 | PoE | DWDR
Lens2.8-12mm
MP5MP
Image Resolutions5MP (2592×1944), 1080P (1920×1080), 720P (1280×720), D1, CIF, (480×240)
Sensor Size1/2.7 inch CMOS
IR Distance98~164 Feet
IP RatingIP67
VoltageDC 12V / PoE
Temp Range-22° F ~ +140° F/ Less than 95% RH
Dimensions5.55in x 3.94in x 3.94in
Weight1.87 lb
AudioN/A
SD Card CompatibleYes
Perimeter ProtectionNo
Object DetectionYes
Face DetectionNo
Face RecognitionNo
Smart Motion DetectionNo
LPRNo

Review the product datasheet when specifying the system. Confirm any conflicting values with the reseller before installation.
