IPFE-SB6IR1A-A

6MP 360° Fisheye IP Camera with Built-in Mic

A 6MP fisheye IP camera with a 360-degree imaging format and integrated microphone. Plan its mounting position to make use of the surrounding view. Check how your recorder or viewing software displays and dewarps the image before specifying the final operator workflow.

Pricing and availability are provided by our authorized reseller.

Technical specifications

FeaturesSupports 3D DNR, WDR, BLC, HLC, Smart IR, Defog | ICR auto switch, true day / night vision | Built-in micro SD card slot, up to 256GB | H.265+/H265/H.264+/H264/ MJPEG coding
Lens1.65mm @F2.0, horizontal field of view: 180°(Wall Mounting), 360°(Ceiling Mounting), 360°(Desktop)
MP6MP
Image Resolutions2160x2160
Sensor Size1/2.5
IR Distance65-98 feet
IP RatingIP67
Voltage12V DC/POE
Temp Range- 30 °C ~ 60 °C (-22°F~140°F); Humidity: less than 95 % (non-condensing)
Dimensions5.11in x 1.6in
Weight1 lb
AudioBuilt In Mic
SD Card CompatibleYes
Perimeter ProtectionYes
Object DetectionYes
Face DetectionYes
Face RecognitionNo
Smart Motion DetectionNo
LPRNo

Review the product datasheet when specifying the system. Confirm any conflicting values with the reseller before installation.
